Reference Facilities

Reference facilities on a commercial scale delivered over a decade of operational success with whole value chain integration: from waste feedstock to product. ​

Since 1926, 40 Winkler gasifiers have been built, 7 of which utilize the HTW® technology. The most notable references built after 1970 are listed below.

Timeline of the HTW® technology

1970s

  • 1970 -

    Rheinbraun and ThyssenKrupp developed the pressurized version of the gasifier known as the High-Temperature Winkler (HTW®) process.

  • Input

    • Waste
    • Biomass
    • Plastic Residues

    Output

    • Methanol
    1986 - 1997
    Commercial plant Berrenrath, Germany

    1986 -

  • Input

    • Peat

    Output

    • Ammonia
    1988 - 1992
    Commercial plant Oulu, Finland

    1988 -

  • Input

    • Fossil Feedstock

    Output

    • Syngas
    1989 - 1992
    High-pressure plant Wesseling, Germany

    1989 -

  • Input

    • MSW

    Output

    • Syngas to CHP
    1999 - 2002
    Demonstration plant Niihama, Japan

    1999 -

  • Input

    • Waste
    • Biomass

    Output

    • Syngas
    2015 - now
    Demonstration plant TU Darmstadt, Germany

    2015 -

  • Today

    2024 -

    Adapted with 100% non-recycables as feedstock.

    Improved to current technological and environmental standards.

    Higher operational efficiency, optimum heat integration and reduced emissions.



1970198619881989199920152024
